OEM/ODM Custom Consumer Electronics Molds / Inner bracket of left rear cover of transparent earphone (1*8) No.24213

Brand Name : Chitwing

Model Number : Earphone Charging Case

Certification : ISO 9001:2015

Place of Origin : China

MOQ : 1set

Price : Negotiable

Payment Terms : L/C, T/T

Supply Ability : 200 set/month

Delivery Time : 30 day(s)

Packaging Details : The mold is packaged with a wooden box and placed on a wood pallet.

Size : 250 X 250 X 251

IMM Tonnage : 80T

Mold Weight : 93KG

Design software : 3D:UG 4.0, 2D:CAD

Mould life : ≥500000 shots

Runner : Cold runner

Part material : translucent PC

Cavity : Harden with 1*16/S136

Core : Harden with 1*16/S136

Contact Now

Transparent Earphone

Charging Box Light Guide (1*16)

No.24213

Injection/Runner Type: Cold runner

Tool life: 500k shots

Part material: translucent PC

This mold was developed by Chitwing (design and manufacturing), using standard mold base,

LKM standard; the molded part has smooth surface and aesthetic appearance w/o burrs;

with mature processing technology, the mold surface hardness > 600HV, with high

anti-wearing and anti-fatigue performance; the mold is designed with cavity ejection pin to

achieve higher demolding efficiency

OEM/ODM Custom Consumer Electronics Molds / Inner bracket of left rear cover of transparent earphone (1*8) No.24213

Mold size: 250 X 250 X 251mm, net weight 93kg, fit 80T machine; the part weight is only 0.2g,

and the part size is (L) 9.6 * (W) 8.6 * (H) 5.2mm

OEM/ODM Custom Consumer Electronics Molds / Inner bracket of left rear cover of transparent earphone (1*8) No.24213

Surface finish A surface polished to SPI-A1
Inner surface EDM with VDI21# (Makino)

OEM/ODM Custom Consumer Electronics Molds / Inner bracket of left rear cover of transparent earphone (1*8) No.24213

Cavity Harden with 1*16/S136
Core

IMM tonnage: 80T

Display diagram

OEM/ODM Custom Consumer Electronics Molds / Inner bracket of left rear cover of transparent earphone (1*8) No.24213OEM/ODM Custom Consumer Electronics Molds / Inner bracket of left rear cover of transparent earphone (1*8) No.24213OEM/ODM Custom Consumer Electronics Molds / Inner bracket of left rear cover of transparent earphone (1*8) No.24213OEM/ODM Custom Consumer Electronics Molds / Inner bracket of left rear cover of transparent earphone (1*8) No.24213
